Emulex LightPulse Dual-Port 32Gb Fibre Channel Adapter (LPE35002-M2)

Emulex LightPulse Dual-Port 32Gb Fibre Channel Adapter (LPE35002-M2)




Applications continue to grow in size and scale and, to support them, enterprises are increasingly turning to new server technologies that contain hundreds of processor cores as well as high-performance storage solutions including low-latency NVMe all-flash arrays (AFAs). NVMe can significantly increase the performance of storage area networks (SANs), making the selection of high-speed networking technology the critical element for achieving maximum system-wide performance.


SKU: LPE35002-M2 Category:
Specification Value
Lifecycle Active
Distributor Inventory Yes
ECD Cable Support 0.5m to 100m at 64GFC/32GFC on 50/125 µm OM4 MMF, 0.5m to 100m at 64GFC/32GFC on 50/125 µm OM5 MMF, 0.5m to 70m at 64GFC/32GFC on 50/125 µm OM3 MMF, 10 km at 32GFC/16GFC on 9/125 µm singlemode fiber when Emulex approved longwave transceivers are used
OS Support Additional support is available from OEMs and partners, Microsoft Windows, Oracle Linux, Oracle Linux with the Unbreakable Enterprise Kernel (UEK), Oracle Solaris, Red Hat Enterprise Linux, SUSE® Linux Enterprise Server, VMware vSphere
Generation Gen 7 (64/32GFC)
Hardware Environment Intel x64, Intel x86, and PowerPC
Host Bus Type PCIe Gen4 x8
Industry Standards Current ANSI/IETF Standards: FC-PI-4, FC-DA, FC-DA-2, FC-FS, FC-FS-3, FC-FS-4, FC-FS-5, FC-GS-2/3/4/5, FC-GS-6, FC-GS-7, FC-LS-2, FC-LS-3, FC-MI, FC-NVMe, FC-NVMe/AM1, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PI-2, FC-PI-3, FC-PI-4, FC-PI-5, FC-PI-6, FC-PI-7, FC-TAPE, FCP-2/3, FCP-4, Legacy ANSI/IETF standards: FC-PH, SBC-3, SPC-3, SPC-4, SSC-2, SSC-3, SSC-4
I/O Controller XE601
Operating Humidity 5% to 95% non-condensing
Operating Temperature [C°] 0°C to 55°C
Optical Data Rates 32GFC (28.05 GBaud NRZ), 16GFC (14.025 GBaud NRZ), 8GFC (8.5 GBaud NRZ), automatically detected
Optics Optics Short wave lasers with LC type connector optics
Ordering Optional Accessories LP32-LW-OPT-1 32GFC Optic (longwave laser with LC connector SFP+ transceiver): 1 pack, LP32-LW-OPT-2 32GFC Optics (longwave laser with LC connector SFP+ transceiver): 2 pack
Ordering Part # LPe35002-M2
Physical Dimensions Short, low profile PCIe card, 167.64mm x 68.91mm (6.60” x 2.71”), Standard bracket (low profile bracket ships in box)
Ports 2
Regulatory Certifications Australia(RCM), Japan(VCCI Class A), China(China RoHS Compliant), EU (Low Voltage Directive), EU RoHS compliant, Europe CE Mark, FCC Class A, Korea (KCC Class A), North America, Taiwan(BSMI Class A), UL/CSA Recognized
Storage Temperature -20° to 85°C (-4° to 185°F)
Whats in the box Each box includes:

  • Quantity 1, low-profile Host Bus Adapter with optic/s
  • Quantity 1, standard bracket (installed)
  • Quantity 1, low-profile bracket
